Corrugated compensator is made of 1 or several stainless steel bellows in series together, stainless steel bellows outside the outer sleeve that allows the bellows to move axially, both to protect the equipment, but also to ensure its stability and reliability. Axial type compound tie rod corrugated compensator can achieve the axial compensation of the pipeline, compensation volume is large, more economic is its characteristic. Axial type compound tie rod corrugated compensator is composed of stainless steel corrugated pipe (some kind of elastic element) and end pipe, support frame, flange, conduit and other accessories that constitute the main body of its operation, can achieve the axial compensation of the pipeline, the compensation volume is large, more economical is its characteristic. Directly buried corrugated expansion joint compensator can achieve the axial compensation of the pipeline, compensation volume is large, more economical is its characteristic. Flange connection according to the machine standard JB81-59 supply, but also according to customer regulations according to national standards, chemical standards or other standards supply. It is a flexible part composed of two bellows with the same geometric parameters and wave number connected by the middle tube and the tie rod and end plate. Mainly used to compensate the lateral displacement of single plane or multi-plane bending pipe section. Compound large tie rod corrugated compensator is suitable for "l" and "z" type pipe system. Compound large tie rod corrugated compensator because the tie rod can withstand pressure thrust and other additional external forces, the expansion joint itself to absorb the internal pressure thrust, will not produce external forces on the pipe, so the pipe at both ends of the expansion joint can use the middle fixed bracket or guide bracket, reduce construction costs, improve construction efficiency.

Instructions for use: Directly buried corrugated expansion joint compensator can achieve axial compensation of pipeline, compensation volume is large, more economical is its characteristic. Flange connection according to the machine standard JB81-59 supply, but also according to customer regulations according to national standards, chemical standards or other standards supply.
